CNC Horizontal Boring Machine

FOB Reference Price:Get Latest Price
$30,000.00 - $90,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
DBM-130A
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Production Capacity:
High
Place of Origin:
Jiangsu, China
Brand Name:
DRC
Voltage:
380V
Dimension(L*W*H):
7690/8190/5600mm
Certification:
ISO CE
Warranty:
1 YEAR
After-sales Service Provided:
Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service
Key Selling Points:
High Safety Level
Applicable Industries:
Manufacturing Plant, Construction works , Energy & Mining
Name:
CNC Horizontal Boring Machine
Product name:
Horizontal boring and milling machining centers
Spinde diameter:
130mm boring and milling machining centers
Center of spindle worktable surface:
125-2725mm Horizontal Boring Machine
X-axis travel (standard):
3000/3500/4500/5500mm
Y-axis travel (standard):
3200mm boring and milling machine
Z-axis travel (standard):
1500mm boring machine
W-axis travel (standard):
700mm Horizontal boring milling machine
Spindle motor:
22/30kw CNC boring machine
Control system:
FANUC
Weight:
49000kg
Motor Power (kw):
30
Supply Ability
Supply Ability:
20 Set/Sets per Month CNC Horizontal Boring Machine
Packaging & Delivery
Packaging Details
CNC Horizontal Boring Machine
wooden casing
Port
Shanghai Port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Product Description
CNC Horizontal Boring Machine

CNC Horizontal Boring Machine

Application field

The CNC boring and milling machine horizontal machining center can meet the needs of various manufacturing fields including energy, petroleum, shipbuilding, structural parts, engineering machinery, aerospace, diesel engines and heavy machinery.

Main Features

1.Spindle adopts German A.M Technology (22/30kw), the maximum speed of up to 3000rpm.
2.The shaft is replaced by the ZF gear box to replace the traditional gear, increasing the spindle torque, and ensuring the stability of the boring depth accuracy
3.The spindle broach is up to 2500-2700kgf, increased by 20% than the other manufacturers.
4.Worktable with the surface by steel combination, cancel the wear plate, using hydraulic technology, so as to strengthen the work of Taiwan wear resistance, to ensure the stability and the service life of precision worktable
5.The X and Z axis adopt heavy duty linear roller guide rail. They are of good rigidity, high accuracy and long service life

Main Parameter

Model
Unit
DBM110A
DBM130A
DBM130B
X-axis travel
mm
2000/2500
3000/3500/4500/5500
4500
Y-axis travel
mm
1800
2600/3200
3500
Z-axis travel
mm
1500
1500/2000
2000
W-axis travel
mm
550
700
700
Spindle
Center of spindle worktable surface
mm
80~1880
125~2125
125~3625
Nose of spindle to work center
mm
-50~2000
100~2300
200~2900
Spinde diameter
mm
110
130
130
Spindle taper
ISO 50
ISO 50
ISO 50
Rotating spindle speed (standard)
rpm/min
35~3500
35~3000
35~3000
Number of steps of rotating speed of spindle
2 Steps
2 Steps
2 Steps
Transmission mode
Gear box
Gear box
Gear box
Worktable
Table size (optional)
mm
1250×1500
1800×2200
(2500×2500)
2500×2500
Division angle
deg
0.001°
0.001°
0.001°
Reference aperture
mm
140H7
Φ140H7
Φ140H7
Max. load on worktable
kg
5000
15000/20000
20000/25000
T-shot
mm
22H7×160×7
24H7×200×7
28H7×150×15
Division precision
sec
15
15
15
Repetitive locating precision
sec
4
4
4
Tool magazine and automatic toolchanger (optional)
Capacity of tool magazine
40
60
60
Tool selecting mode
Absolute
Absolute
Absolute
Tool changing type
Arm type
Arm type
Arm type
Tooling
BT/CAT/DIN #50
BT/CAT/DIN #50
BT/CAT/DIN #50
Max. tool weight
kg
25
25
25
Max. tool length
mm
500
500
500
Max. tool diameter (no adjacent tool)
mm
Φ125/250
Φ125/250
Φ125/250
Spindle and motor
Spindle motor
kw
FANUC 18.5/22
FANUC 22/30
FANUC 22/30
Max. torque of spindle
Nm
965/1155
3011/4109
3011/4109
Locating precision of machine tool
mm
±0.010
±0.010
±0.010
Repetitive locating precision of machine tool
mm
±0.005
±0.005
±0.005
Others
Floor area (length×width×height)
mm
6405×6250×5415
7690×8190×5600
7690×9690×6500
Machine weight
kg
30900
49000
55000
Process Details

X/Y/Z Axis structures

Meehanite castings in integrated casting formation and resistant to abrasion, stress elimination enables high shock resistance, and the capability of vibration absorption is higher than common cast iron, so as to improve stability of machine tool.
Oil and coolant are recycled for prevention of pollution and in compliance with the requirements of environmental protection.

Spindle

Gear type main shaft head are integrally cast molding, has a higher rigidity than the average combined type main shaft structure, improves the stability of the machine.
Spindle using large spacing, cylindrical rollers NN bearing ultra precision, ultra rigid, therefore has excellent processing capability for heavy cutting.

Worktable

Indexing action is kept reliable and stable dependent on drive of large-diameter sliding surface and double gears 90°locating pins independently researched .

In addition hydraulic and T-bolts are used for solid clamp. Furthermore, backboard is used to prevent float of worktable under strong clamp of hydraulic and T-bots.

Reliable automated tool magazine
The automatic tool changer consists of a tool magazine and a tool changer arm. Automatic tool changer is separate from machine tool Installation, the purpose is to prevent vibration or other reasons for the accuracy of the automatic tool changer operation Produces an unfavorable camera. The tool selection uses the shortest path fixed address method. All tools Return to the original position, so there is a large size tool collision problem only when first installed Take the test. The bidirectional tool magazine uses the shortest path.
Related Products
Ender Users&Delivery
Why Choose Us

COMPANY INTRODUCTION:

DRC is a group company ,which is professional in products and sales of advanced CNC machine tools . Acting full operation of the six machine tool production company's overseas sales.
DRC is located in Dalian, which is one of the largest seaport cities of China.Our products exported to Russia, Dubai, Hungary, Italy, Argentina, the Philippines, India, Iran, more than 50 countries.
DRC has six factories in China, which covers many kinds of mechanical equipment.
Product Range:

Lathe
CNC Lathe
Conventional Lathe,
Vertical Lathe
Machining Center
Boring and Milling Machine
◎CNC
 Milling Machine
Glass Tempering Furnace
Special Machine for Pipe Threading Lathe ,Valve Milling, End Facing and so on


After-Sale Service
FAQ

1. What is your minimum order quantity and warranty?

 MOQ is one set, and warranty is one year.

2.What CNC system do you use?

FANUC, SIEMENS, MISTSUBISHI, GSK etc. It depends on your choice.

3.When is the delivery time?

We will delivery it within 90 days after received your payments

4. How to handle the warranty period?

During the warranty period, because of product quality problems, the company is responsible for free maintenance, if need to change parts, we be responsible for free replacement.
If the machine problem is not belonging to our machine quality problems, when the buyer needs us send engineers to give repairing service, we charge the appropriate cost.

5.Can your company send the technical personnel to our company and direct our workers for free?

When the machine arrive the buyer's installation site, we timely send mechanical and electrical engineers to install according to the buyer's schedule, the buyer undertakes board and lodging of personnel abroad in the process of installation, and also USD100.00 per day per person. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
